Vetus Bow thruster 75kgf 12V D185mm ignition protected

Description Reviews

Vetus Bow thruster 75kgf 12V D185mm ignition protected Installing an electric bow or stern thruster in a petrol (gasoline) engined boat can be very dangerous, due to the possibility of the electric motor igniting fuel vapour. In order to eliminate the risk, this special housing will shield the bow or stern thruster from potentially explosive vapour. The housing enables the thruster to comply with the ISO 8846 Marine “ignition protection” standard. In addition to the standard thruster, the set consists of a watertight (IP65) housing for the electric motor and relays, together with all required seals, electrical connectors and fastening components.An automatic fuse for the control loom is also supplied. This can be reset externally without opening the housing. For both 12 and 24 volt supply. They can also be used as stern thrusters, in combination with the appropriate kit. Because the motor housing is watertight, these sets are also ideal for use where the bow or stern thruster is installed in a wet or humid space. Voltage (V) 12 V Current consumption (A) 500 Continuous operating time (min) 2 Main fuse "slow blow" (A) 355 Batteries 12 V, min./max. Ah 1x120 / 1x225 Battery main switch: model BATSW / type BPMAIN 250 / 12 Max. operating time (minutes) 2 Motor, reversible D.C. Yes Ignition protection Yes Thrust (N / lbf) 800 / 176 Power (hp) 6 Internal tunnel diameter (inches) 7 9/32 Weight (lbs) 57 Battery cables, length pos./neg. cables (ft/AWG) 0- 26,24/00 (2/0) 26,24- 36,08/000 (3/0) Size A in inches, see drawing 9 3/8 Size B in inches, see drawing 18 7/64 Size C in inches, see drawing 3 1/32 Size D min./max. in inches, see drawing 14 9/16 / 29 9/64 Size E in inches, see drawing 11 21/32 Size F, diameter in inches, see drawing 9 29/64 Size G min. in inches, see drawing 7 9/32 Size H, diameter in inches, see drawing 7 9/32 Thrust (N / kgf) 800 / 80 Power (kW) 6 Internal tunnel diameter (mm) 185 Weight (kg) 26 Battery cables, length pos./neg. cables (m/mm²) 0-8/70 / 8-11/95 Size A in mm, see drawing 238 Size B in mm, see drawing 460 Size C in mm, see drawing 77 Size D min./max. in mm, see drawing 370 / 740 Size E in mm, see drawing 296 Size F, diameter in mm, see drawing 240 Size G min. in mm, see drawing 185 Size H, diameter in mm, see drawing 185 There are currently no reviews for this product. Click here to submit a review
