Humminbird XTM 14 HW MDI T - Trolling Motor Mounted MDI+ Dual Spectrum CHIRP Transducer

Humminbird XTM 14 HW MDI T - Trolling Motor Mounted MDI+ Dual Spectrum CHIRP Transducer

Trolling Motor Mount, MEGA Down Imaging+ 800kHz/455 kHz and 1.2 MHz and Dual Spectrum CHIRP 2D Sonar with a CHIRP range of 150-220kHz. Includes built-in temperature sensor

Compatible With
All APEX models, All SOLIX models to the maximum capability of the transducer

Cable Length
15 feet

Dual Spectrum CHIRP Frequencies
Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz

Dual Spectrum CHIRP Max Depth
1200ft (365m)

MEGA Down Imaging Frequencies - Max Depth
455kHz: 440-500 kHz - 400ft (122m), 800kHz: 790-850 kHz - 125ft (38m), MEGA DI+: 1075-1150 kHz - 200ft (61m)

Notice
This transducer will not fit Minn Kota trolling motors with less than 80 pounds of thrust as it measures 7.15" long by 2.3" wide and will not fit between the prop and the skeg.

Warranty
1-Year Limited Warranty
