Vetus Bow thruster 55kgf 12V D150mm

Manufacturers Part Number: BOW5512D


Our Price:
  Inc VAT
  ex VAT
Order Code: ZVETBOW5512D
Manufacturer: Vetus
RRP:   Inc VAT

Standard UK delivery is currently
7 - 10 working days
on this product.


Delivery Options
Choose Destination
Postcode/ZIP:

Standard UK Delivery
7 - 10 Working days
(inc TAX)
FREE


Vetus Bow thruster 55kgf 12V D150mm

  • Advantages of VETUS bow thrusters
  • A single propeller creates less flow disturbance in the tunnel
  • The VETUS unique propeller blade design minimises cavitation noise
  • The use of a flexible coupling between tail piece and motor eliminates vibration
  • All VETUS systems use a streamlined tail piece for optimum flow
  • A strong synthetic propeller eliminates corrosion and reduces weight
  • Systems are easy to install, supplied with clear installation and operation instructions
  • VETUS systems use a new line of high quality aluminium control panels which are interchangeable with older panels
  • All VETUS manoeuvring systems meet the EMC requirements
  • Voltage : 48 Volt DC

    Voltage (V)12 V DC
    Current consumption (A)350
    Continuous operating time (min)4
    Main fuse "slow blow" (A)250
    Batteries 12 V, min./max. Ah1x105 / 1x200
    Battery main switch: model BATSW / type BPMAIN250 / 12
    Max. operating time (minutes)4
    Motor, reversible D.C.Yes
    Ignition protectionNo
    Thrust (N / lbf)550 / 55
    Power (hp)4
    Internal tunnel diameter (inches)5 29/32
    Weight (lbs)44
    Battery cables, length pos./neg. cables (ft/AWG)0- 39,37/00(2/0)
    Size A in inches, see drawing5 5/8
    Size B in inches, see drawing14 27/32
    Size C in inches, see drawing3 7/64
    Size D min./max. in inches, see drawing11 13/16 / 23 5/8
    Size E in inches, see drawing6 19/64
    Size F, diameter in inches, see drawing5 1/8
    Size G min. in inches, see drawing5 29/32
    Size H, diameter in inches, see drawing5 29/32
    Thrust (N / kgf)550 / 55
    Power (kW)3
    Internal tunnel diameter (mm)150
    Weight (kg)20
    Battery cables, length pos./neg. cables (m/mm²)0-12 / 70
    Size A in mm, see drawing143
    Size B in mm, see drawing377
    Size C in mm, see drawing79
    Size D min./max. in mm, see drawing300 / 600
    Size E in mm, see drawing160
    Size F, diameter in mm, see drawing130
    Size G min. in mm, see drawing150
    Size H, diameter in mm, see drawing150
