Simarine SCQ25 Quadro Digital Shunt Module SIMARINE SCQ25 is a highly versatile shunt module. It is equipped with four shunts to measure voltage and current up to 25A. It is ideal to monitor independent consumer (e.g. refrigerator, instruments, lights) or generator devices (e.g. solar, wind generator) and measure their exact consumption or gain, respectively.
Up to five modules can be connected simultaneously to monitor up to 20 current channels. Specifications: Operating
Voltage range 6 - 35 V
Temperature range -20 - +70 °C
Power consumption at 12V
Operating 3,5 mA
Current measuring channels 4
Current measuring range
Per channel 0,01 – 50 A
Accuracy ± 0,6 %
Resolution 0,01 A
Sampling rate 100 ms
Maximal current
Continuous 25 A
Peak current (<1 min) 35 A
Peak current (<5 sec) 50 A
Voltage drop at 25 A 35 mV
Maximal voltage on connections 35 V |
