Seaflo WAS12001 Bilge Water Level Alarm System - 20A Max - 12VThe SEAFLO electronic water level alarm control system is an intelligent safety system which incorporates a visual & auditory warning plus switch control. Used in conjunction with a water level electronic switch, when the water level in the vessel is higher than the safety line, the system will emit a red signal light, and at the same time it sounds a ≥85DB alarm. When the water level falls back to the safe level, the alarm is silenced & the light turns off.
- Detects water & sends a signal to the alarm & control panel switch
- Electric field bilge Switch is rated to handle all bilge pumps up to 20A at 12V & 10A at 24V.
- Switch activates at 41mm fluid level & deactivates at 9.5mm fluid level
- 3 second delay prevents false starts
- Totally sealed fluid detector is never in contact with water, will not corrode & is not affected by oil or debris
- Environmentally safe - no mercury
- No moving parts
- Unique 3-way switch disables alarm while keeping warning LED lit
Specifications:
Art No.
| Volts
| Max Amps
| Alarm Volume
| Outlet
| Wire
| WAS12001
| 12V | 20A | 95dB
| 19mm / 3/4"
| 18 AWG x 1m (Switch) 28 AWG x 15cm (Alarm)
|
|
