Rated Output Power @86°F (30°C): 3000W
Surge Power (100 ms): 6000W
Surge Power (3 seconds): 4500W
Surge Power (35 seconds): 3600W
Nominal Output Voltage RMS: 230(±3%)V AC
Output Frequency: 50Hz (±0.1Hz) (Default) / 60Hz (±0.1Hz)
Output Wave Form: Pure Sine Wave
Nominal Input Voltage: 12V DC
Input Voltage Range: 9V to 16.5V DC (±0.3V) (Full load 10.5V to 15.5V DC)
Short Circuit Protection: Software Protection
Total Harmonics Distortion (THD): < 4% (Resistance load)
Maximum Nominal Efficiency: 91% peak
No Load Power Consumption: <10W
Operating Temperature Range: -4°F to 122°F / -20°C to 50°C (Output power degrading at 86°F/30°C or higher)
Storage Temperature: -22°F to 158°F / -30°C to 70°C
Dimensions: 17.02 x 12.01 x 4.46 in (432.4 x 305 x 113.3 mm)
Weight: 16.98 lbs / 7.7 kg
