Lewmar C3 Capstan - Integrated Deck Unit / Motor Gearbox - 24VLewmars C Series Capstans provide almost effortless rope control at the press of a footswitch. The WARP (Wear and Abrasion Resistant Pattern) finished drum optimizes performance and reduces rope wear by up to 30%. Stainless steel components combine strength, anti-corrosion and durability with a beautiful, polished finish. Installation of the C3 is quick and simple, as it is fastened entirely from above deck. This innovation cuts installation time by 35%.
Features
- Beautifully crafted stainless steel components ensure enduring strength and performance
- WARP finish drum - unique Wear and Abrasion Resistant Pattern reduces rope wear by 30%
Specification:
| Motor Power | Max Pull (kg) | Working Load (kg) | Max Line Speed (m/min) | Normal Current Draw | Circuit Breaker | Weight (kg) |
|---|
1000W | 850 | 213 | 12 | 40A | 50A | 12 |
| A (mm) | B (mm) | D (mm) | H1 (mm) | H2 (mm) |
|---|
| 80 | 165 | 90 | 137 | 194 |
|
