BlueSea Switch Panel - Below Deck 12V DC Circuit Breakers 6 Switches

Description Reviews

BlueSea Switch Panel - Below Deck 12V DC Circuit Breakers 6 Switches DURABLE Molded panel frame will stand up to UV and salt air EASY Low profile makes it easy to install in tight spaces SIMPLE Fast-on circuit breaker connectors make it quick to wire CONVENIENT Red “ON” indicating LEDs for safe operation in low light conditions 6 Carling Technologies™ 15A circuit breakers Illuminated ON indication Polycarbonate/ABS panel surface is UV-stabilized, flame retardant, and will not corrode Quick connect BUS eliminates wire harness and clutter contributing to a low profile panel Two-wire connection for powering all panels is simple and requires #10 ring terminals. Terminals screw to bus bars for secure connections Set of 15 square format circuit labels are included, and are easy to replace. Additional standard or custom labels are available through Blue Sea Systems Stainless steel #6 x 5/8″ mounting screws included   Specifications Positions 6 Nominal Voltage 12V DC Maximum Amperage  45A Terminal Type 1/4″ Male quick connect Hardware Stainless Steel #6 x 5/8″ mounting screws Ring Terminal Size M5 (#10) Height 6.5in (165.1 mm) Width 4.5in (114.3 mm) Depth 1.75in (44.45 mm)   There are currently no reviews for this product. Click here to submit a review
