Victron Energy Skylla-IP65 Battery Charger - 24V-35A - 3 OutputsA powerful, waterproof and intelligent battery charger with a 7-stage adaptive charge algorithm, suitable for a wide range of battery types and chemistries featuring a dedicated Lithium-ion charge algorithm.
The wide range universal input voltage adds flexibility to the installation, the charger will maintain its full output power no matter where it is located in the world.
The IP65 rating makes this charger especially suitable for marine, mobile, and industrial applications and it can withstand the rigors of an adverse environment: heat, humidity and salt air.
Both models are available in two versions:
3 full rated outputs
1 full rated output together with an isolated 3A trickle charge output for a starter battery
Input voltage (VAC) - 120/230 V
Input voltage range (VAC) - 90-265 V
Maximum AC input current @ 100 VAC - 12 A
Frequency - 45-65 Hz
Power factor - 0,98
Charge voltage 'absorption' - 28,8 V
Charge voltage 'float' - 27,6 V
Charge voltage ‘storage’ - 26,4 V
Charge current (2) 70 A 3 x 70 A
(max total output: 3 x 35 A (max total output: 35 A)
Charge current starter batt. - n. a.
Charge algorithm - 7 stage adaptive
Battery capacity - 150-350 Ah
Charge algorithm, - Li-Ion 3 stage, with on-off control or CAN-bus control
Temperature sensor - Yes
Can be used as power supply - Yes
Remote on-off port - Yes (can be connected to a Li-Ion BMS)
CAN-bus communication port (VE.Can) - Two RJ45 connectors, NMEA2000 protocol, not isolated
Synchronised parallel operation - Yes, with VE.Can
Alarm relay DPST AC rating: 240 VAC/4 A DC rating: 4 A up to 35 VDC, 1 A up to 60 VDC
Forced cooling - Yes (internal air circulation)
Protection - Battery reverse polarity (fuse) Output short circuit Over temperature
Operating temp. range -20 to 60 °C (Full output current up to 40 °C)
Humidity (non-condensing) - max 95 %
ENCLOSURE
Material & Colour - steel (blue RAL 5012)
Battery-connection - M6 bolts
230 VAC-connection - screw-clamp 6mm² (AWG 10)
Protection category - IP65
Weight - 6 kg (14 lbs)
Dimensions (hxwxd) 401 x 265 x 151 mm / 16 x 10,5 x 6 inch
STANDARDS
Safety - EN 60335-1, EN 60335-2-29
Emission - EN 55014-1, EN 61000-6-3, EN 61000-3-2
Immunity - EN 55014-2, EN 61000-6-1, EN 61000-6-2, EN 61000-3-3 |
