Victron Energy MultiPlus Compact Inverter/Charger - 24/2000/50-30 230V - VE.BusTwo AC Outputs
The main output has no break functionality. The MultiPlus takes over the supply to the connected loads in the event of a grid failure or when shore/generator power is disconnected. This happens so fast (less than 20 milliseconds) that computers and other
electronic equipment will con tinue to operate without disruption. The second output is live only when AC is available on the input of the MultiPlus. Loads that should not discharge the battery, like a water heater for example can be connected to this output (second output available on models rated at 3 kVA and more).
Virtually unlimited power thanks to parallel operation Up to 6 Multis can operate in parallel to achieve higher power output. Six 24/5000/120 units, for example, will provide
25 kW / 30 kVA output power with 720 Amps charging capacity.
Three phase capability
In addition to parallel connection, three units of the same mo del can be configured for three phase output. But that’s not all: up to 6 sets of three units can be parallel connected for a 75 kW / 90 kVA inverter and more than 2000 Amps charging capacity.
PowerControl - Dealing with limited generator, shore side or grid power
The MultiPlus is a very powerful battery charger. It will therefore draw a lot of current from the generator or shore side supply (nearly 10 A per 5 kVA Multi at 230 VAC). With the Multi Control Panel a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.
PowerAssist - Boosting the capacity of shore or generator power
This feature takes the principle of PowerControl to a further dimension. It allows the MultiPlus to supplement the capacity of the alternative source. Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery.
Solar energy: AC power available even during a grid failure
The MultiPlus can be used in off grid as well as grid connected PV and other alternative energy systems. Loss of mains detection software is available.
System configuring
- In case of a stand-alone application, if settings have to be changed, this can be done in a matter of minutes with a DIP switch setting procedure.
- Parallel and three phase applications can be configured with VE.Bus Quick Configure and VE.Bus System Configurator software.
- Off grid, grid interactive and self -consumption applications, involving grid -tie inverters and/or MPPT Solar Chargers can be configured with Assistants (dedicated software for specific applications).
On-site Monitoring and control
Several options are available: Battery Monitor, Multi Control Panel, Ekrano GX or other GX devices, smartphone or tablet (Bluetooth Smart), laptop or computer (USB or RS232).
Remote Monitoring and control Ekrano GX or other GX devices. Data can be stored and displayed on our VRM (Victron Remote Management) website, free of charge.
Remote configuring
When connected to the Ethernet, systems with a Ekrano GX or other GX device can be accessed and settings can be changed remotely.
Specifications:
Nominal Battery voltage - 24V
PowerControl - Yes
PowerAssist - Yes
AC input - Input voltage range: 187 -250 V Input frequency: 50/60 Hz Cos Φ >0.8
Transfer switch (A) - 16
INVERTER
Input voltage range (VDC) - 19 – 33 V
Input current (A DC) - N.a
Output Output voltage: 230 VAC ± 2 % Frequency: 50 Hz ± 0,1 % (1)
Cont. output power at 25 °C (VA) - 2000
Cont. output power at 25 °C (W) - 1600
Cont. output power at 40 °C (W) - 1400
Cont. output power at 65 °C (W) - 1000
Peak power (W) - 4000
Maximum continuous Output current (A~) - N.a
Power factor range - N.a
Maximum output fault current - N.a
Maximum efficiency (%) 94
Zero load power (W) - 11
Zero load power in AES mode (W) - 9
Zero load power in Search mode (W) - 4
CHARGER
AC Input - Input voltage range: 187 -265 VAC Input frequency: 45 – 65 Hz Power factor: 1
Charge voltage 'absorption' (VDC) - 28,8
Charge voltage 'float' (VDC) - 27,6
Storage mode (VDC) - 26,4
Charge current house battery (A) - 50
Charge current starter battery (A) - 4 (12 V and 24 V models only)
Battery temperature sensor - yes
GENERAL
Auxiliary output (5) - N.a
Programmable relay (6) - Yes
Protection (2) - a - g
VE.Bus - communication port For parallel and three phase operation, remote monitoring and system integration
General purpose com. port - N.a
Remote on-off - Yes
Operating temp. range: -40 to +65 °C (fan assisted cooling) Humidity (non -condensing): max 95 %
Maximum altitude - 2000 m.
ENCLOSURE
Material & Colour: aluminium (blue RAL 5012),
Protection category: IP20, pollution degree 2, OVC III Icw: 6kA 30mS
Battery-connection - M8 Bolts
230 VAC-connection - Spring Clamps
Weight (kg) - 12
Dimensions (hxwxd in mm) - 520 x 255 x 125
STANDARDS
Safety - EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1
Emission, Immunity EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Road vehicles - 12 V and 24 V models: ECE R10-4 |
