Vesper Marine External Alarm with AlarmMute Switch Kit

Manufacturers Part Number: 141005
Vesper Marine External Alarm with AlarmMute Switch Kit
Product Information
Our Price:

( Inc VAT)
Shipping Cost: Shipping Calculator
Order Code: ZVES141005
Manufacturer: Vesper Marine
Standard UK delivery is 12 - 14
working days on this product.

ADD TO
BASKET
Go To Checkout
GO TO
CHECKOUT
Raymarine Price Increase

Vesper Marine External Alarm with AlarmMute Switch Kit

Loud External Alarm for XB-8000

The WatchMate XB-8000 smartAIS has the ability trigger an external alarm which can be mounted anywhere on board. If the XB-8000 detects a risk situation due to a potential collision, anchor drag or a MOB activation, it alerts you with an alarm on your mobile device. It simultaneously sounds the external alarm which operates even if your mobile device is turned off.

The alarm is designed to be easily mounted and can be connected directly to the XB-8000 without the need for external relays or other components. By simply rotating the sound output vane you can control the volume level.

It is easily configured to make a steady continuous or pulsing tone like a truck back up alarm. It is heavy duty and very robust. Its terminals are via screw down or you can use 6.35mm (1/4") quick disconnects.

This alarm can be used with both 12 and 24 VDC systems. It also has reverse polarity protection to prevent damage due to incorrect wiring.

The Switch is used to mute the Alarm. Its 304 stainless steel body is durable and water-proof making it ideal for mounting both internally or externally. It is designed to be used with 12 and 24 VDC systems.

Alarm Specifications:

Rated voltage12-32 VDC (reverse polarity protected)
Maximum voltage32 VDC
Maximum current35 mA
Frequency2.9 kHz (+/- 0.5)
ConfigurationMakes either a steady or pulsed sound (choose S or P terminal)
Sound pressure85 steady, 80 pulsed dBA/30cm
Volume adjustmentTwist front vane holes to closed to reduce volume
Pulse rate0.8 - 1.2 pulse/sec
SizeDiameter: 43.5mm (1 3/4"), Height: 34.5mm (1 3/8")
Mounting hole29mm (1 3/16")

Switch Specifications:

Voltage Range10-32 VDC
LED ColorBlue
Button & Body304 Stainless Steel
Contact MaterialSilver Alloy
Cable150mm (6”) Tinned
Panel Thickness1~ 10mm
Operating Temp-20C~ +55C
Insulation Resistance≥ 1000MΩ
Contact Resistance≤ 50mΩ
Degree of ProtectionIP65
