Blue Sea Dual Circuit Batt Switch

Simultaneously switches two isolated battery banks
  • Ignition protected safe for installation aboard gasoline powered boats
  • Case design allows surface or rear panel mounting

Specifications
Switch Type Dual Circuit
ColorRed
Switch Positions2
Battery CombineNo
Alternator Field Disconnect No
Maximum Voltage32V DC
Continuous Rating 350A
Intermittent Rating 525A (5 min)
Cranking Rating 10 sec 1000A
Cranking Rating 1 min 750A
Battery Inputs2
Cable Clearance For 4/0 AWG Cables1.10in (27.94 mm)
Cable Size to Meet Ratings4/0 AWG (120mm²)
Mounting HolesAccept 1/4" (M6) Screw
Terminal Stud Size3/8" - 16 (M10)
Terminal Stud Torque140 in-lb (15.82 Nm)
Weight1.30lb (0.59 kg)
