ADVANCED SONAR FEATURES
· Switchfire Sonar
· Screen Snap Shot to Memory Card
· Sonar Recording
· Split Screen Zoom
· Split Screen Bottom Lock
· Wide Narrow Cone Split Screen
· Instant Image Update
· Freeze Frame with the ability to Mark Structure on Sonar
· Selective Fish ID+
· Real Time Sonar RTS Window
· Sonar Echo Enhancement
· TrueArch Technology
USER-FRIENDLY TECHNOLOGY
· 3D Chart View
· Large Digits View
· Custom View Selections
· Custom Digital Readout Selection
· Selectable Display Colors
· Selectable Background Colors
· View Preset Keys
· Temperature Graph
· Temperature Alarm
· Triplog
· X-Press™ Menu System
Display Size:
7.0" diagonal
Display Pixel Matrix:
480V x 800H
Display Type:
16:9 Color TFT
Display Colors/Grayscale:
65,000 Colors
DualBeam PLUS
Sonar Coverage
· 200 kHz / 20° @ -10db
· 83 kHz / 60° @ -10db
Sonar Optional:
QuadraBeam PLUS
Target Separation:
2.5 inches
Power Output (RMS):
500 Watts (RMS)
Power Output (Peak to Peak):
4000 Watts (Peak-to-Peak)
Temperature:
Included
Speed:
GPS Speed Included
Backlight:
Yes
Waterproof:
Mount:
Gimbal
Unit Size:
11" W x 6" H x 4" D
In-dash
11" W x 6" H x 2" D
Transducer Mounting:
Inside Hull or Transom
Power Input:
10-20 VDC
Power Draw:
Lights off: 780mA
